AGSN 12kV air-insulated Unit Metal-enclosed Cabinet

Production Instruction

AGSN switchgear is 12kV air-insulated switchgear featuring modular design. The switchgear uses
Schneider AS12 three-position SF6 switches which are assembled in complete set factory, characterized
by simple structure, flexible scheme, easy-to-use, high safety and reliability. Based on different applications
and various user demands, satisfactory solutions will be provided.

Application

Medium-voltage/low-voltage Substation

Definitions

The followings are ASGN Series products used for medium-voltage/lowvoltage
substations and industrial and mining power distribution stations
ISC: load switch incoming line, outgoing line or connecting cabinet
QSC: fuse + load switch combination cabinet
ESC: Disconnector + vacuum circuit breaker cabinet
PSC: voltage transformer cabinet
GC: current/voltage metering cabinet
DSC: dual power supply incoming line cabinet
GB: bus lifting cabinet
GA: incoming cable connection cabinet
CSC: Transformer Cabinet for Substation
Other cabinets: please consult with the manufacturer

Normal Application

The medium-voltage electric energy generated by power plant is transmitted to high-voltage power grid through MV/HV main transformer.
In general, the electric power is transmitted to primary substation through overhead line.
In HV/MV primary substation, the electric power is converted into medium voltage from high voltage.
in MV/MV primary substation, the electric power is transmitted to several secondary substations at lower level. The circuit breakerplays an important role in power transmission and distribution.
